Plan 9811

Plan Features

RV Garage Plans

Plan Details

Bays	3
Levels	1
Width	40'
Depth	40'
Height	22'
Exterior wall	2x6
Foundation	Footing and Foundation Wall
Roof framing	Roof Trusses
Roof pitch	6/12 Main Roof
Ceiling height	16-0 RV Side, 10-0 Garage Side
Garage Door Size	12' Wide x 14' Tall - RV Side
Garage Door Size	16' Wide x 8' Tall - Garage Side

The tall walls on the RV side of the building are framed with 2×6 studs. The walls on the garage side are framed with 2×4 walls. Select the 2×6 option if you want the entire garage to be framed with 2×6 studs.
